Taylor T-1000 Draft Blower 265 CFM (#12190)

Product Description

Compatible with Taylor T-1000 Shaded Pole Blower, Air Flow @ 0.000 Inch Static Pressure 265 CFM, RPM 1610 For a diagram for the dimensions below please click to pictures 2 and 3 above. Inlet Dia. (In.)4-5/8 Outlet Height (In.)3-11/16 Outlet Width (In.)4-1/8 Overall Height (In.)9-7/8 Overall Width (In.)7-9/16 Overall Depth (In.)8-7/8 Dimension A (In.)8-7/8 Dimension B (In.)9-7/8 Dimension C (In.)7-9/16 Dimension D (In.)4-3/16 Dimension E (In.)10-7/8 Dimension F (In.)3-5/16 Dimension J (In.)5-1/2 Dimension K (In.)5 Dimension L (In.)4-7/8 Dimension M (In.)4-3/8
